Electro-Voice EV Q66 2-Channel Power Amplifier

Electro-Voice EV Q66 2-Channel Power Amplifier. Ideaalses seisukorras.

The Q66 amplifier is based on EVs reference-standard P-Series. It guarantees the same high-quality construction and output, restricted only by the maximum power capability of 2 x 600 watts. The Q66 is designed for cost-limited mobile applications or smaller installations. It includes rear-mounted, dB-scaled, level controls, and is packed into a three-rack-space, zinc-plated steel housing.

Specifications
Amplifier Gain (dB) 34.6dB
Continuous rated power 2ohm 850 Watts
Continuous rated power 4ohm 600 Watts
Input Impedance (balanced) 20 kΩ
Continuous rated power 8ohm 380 Watts
Continuous rated power
(20-20k Hz, THD<0,2%) 4ohm 500 Watts
Continuous rated power
(20-20k Hz, THD<0,2%) 8ohm 300 Watts
Maximum bridged output 4ohm 1700 Watts
Maximum bridged output 8ohm 1200 Watts
Slew Rate > 30 V / s
Electronics Type Amplifier
Network Control (IRIS-Net) No
Total harmonic distortion < 0.05 %
Intermodulation Distortion (SMTPE) < 0.08 %
Signal-to-noise ratio (A-weighted) > 105 dB
Input Sensitivity 0 dBu / +6 dBu
Weight Net 16 kg ( 35.27 lbs )
Dimensions (HxWxD) 133 x 483 x 386 mm
