Monitor EIZO FlexScan EV2455 24.1" IPS LED

Cabinet Color Black

Panel

Type IPS

Backlight LED

Size 24.1" / 61 cm (611 mm diagonal)

Native Resolution 1920 x 1200 (16:10 aspect ratio)

Viewable Image Size (H x V) 518.4 x 324.0 mm

Pixel Pitch 0.270 x 0.270 mm

Display Colors 16.77 million

Viewing Angles (H / V, typical) 178°, 178°

Brightness (typical) 300 cd/m2

Contrast Ratio (typical) 1000:1

Response Time (typical) 5 ms (Gray-to-gray)

Video Signals

Input Terminals D-Sub mini 15 pin x 1, DVI-D 24 pin x 1 (with HDCP), HDMI x 1 (with HDCP), DisplayPort x 1 (with HDCP)

Digital Scanning Frequency (H / V) 31 - 76 kHz, 59 - 61 Hz (VGA Text: 69 - 71 Hz)

Analog Scanning Frequency (H / V) 31 - 81 kHz, 55 - 76 Hz

Sync Formats Separate

USB

Function 1 port for monitor control

2-port USB hub

Standard USB 3.0

Audio

Speakers 1.0 W +1.0 W

Input Terminals 3.5 mm stereo jack

Output Terminals 3.5 mm headphone jack

Sound Adjustment Volume, Power Save, Source (DisplayPort, HDMI)

Power

Power Requirements AC 100 - 120 V / 200 - 240 V, 50 / 60 Hz

Maximum Power Consumption 49 W

Typical Power Consumption 13 W

Power Save Mode Less than 0.3 W

Power Management Power Save (VESA DPM, DisplayPort Rev. 1.1a, and DVI DMPM), Eco Timer

Features & Functions

Preset Modes Color mode (Paper, Movie, sRGB, User1, User2, DICOM)

Auto EcoView / BrightRegulator Yes

EcoView Sense Yes

OSD Languages English, French, German, Italian, Japanese, Simplified and Traditional Chinese, Spanish, Swedish

Physical Specifications

Dimensions (Landscape, W x H x D) 530.8 x 368 - 488.2 x 233 mm

Dimensions (Without Stand, W x H x D) 530.8 x 347.2 x 47.9 mm

Net Weight 6.5 kg / 14.3 lbs

Net Weight (Without Stand) 4.1 kg / 9.0 lbs

Height Adjustment Range 131 mm (maximum 140mm)

Tilt 35° Up, 5° Down

Swivel 344°

Pivot 90°(both clockwise and counter clockwise)

Hole Spacing (VESA Standard) 100 x 100 mm

Environmental Requirements

Operating Temperature 5 - 35 °C

Operating Humidity (R.H., non condensing) 20 - 80 %

Certifications & Standards (Please contact EIZO for the latest information.) TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, GOST-R

Supplied Accessories AC power cord, signal cables (DisplayPort - DisplayPort), USB cable, EIZO LCD Utility Disk (PDF user's manual), setup guide
