Nord mootorreduktorid

Müüa uued kasutamata Nord reduktormootorid originaalpakendis.

1. SK 5282ABHG - 132SP/4 TF F
Type: Parallel Shaft Gears BLOCK
Input Speed: 1465 1/min
Ratio: 55.9
Output Speed: 26 1/min.
Service Factor: 1.3
Output torque: 2006 Nm
Power: 5.5 kW
Voltage: 400/690 V
Efficiency Class: IE3
Mounting Pos: M5
Output Shaft: Hollow Keyed 60H7 mm
Gearbox Options: Shaft Fixing Kit; Rubber Buffers; Cover Hollow Shaft
Motor Cooling: TEBC Totally Enc Blower Cooled 3ph & 1ph 220-575V 50/60Hz
Paint Color: RAL 5010 Blue
Kogus: 1 tk.

2. SK 9032.1AZBHK - 100AP/4 TF F
Type: Helical Bevel Gears BLOCK
Input Speed: 1450 1/min
Ratio: 35.61
Output Speed: 41 1/min
Service Factor: 2.2
Output torque: 704 Nm
Power: 3 kW
Voltage: 400/690 V
Efficiency Class: IE3
Mounting Pos: M3
Output Shaft: Hollow Keyed 50H7 mm
Gearbox Options: Shaft Fixing Kit; Cover Hollow Shaft; Bottom Mount Torque Arm
Motor Cooling: TEBC Totally Enc Blower Cooled 3ph & 1ph 220-575V 50/60Hz
Paint Color: RAL 5010 Blue
Kogus: 1 tk.

3. SK 9032.1AZBHKR - 132SP/4 TF F
Type: Helical Bevel Gears BLOCK
Input Speed: 1465 1/min
Ratio: 23.91
Output Speed: 61 1/min
Service Factor: 1.8
Output torque: 857 Nm
Power: 5,5 kW
Voltage: 400/690 V
Efficiency Class: IE3
Mounting Pos: M1
Output Shaft: Hollow Keyed 50H7 mm
Gearbox Options: Shaft Fixing Kit; Cover Hollow Shaft; Bottom Mount Torque Arm, Backstop
Backstop Rotation: Clockwise Rotation Allowed when Viewing the Output Shaft Side B
Motor Cooling: TEBC Totally Enc Blower Cooled 3ph & 1ph 220-575V 50/60Hz
Paint Color: RAL 5010 Blue
Kogus: 1 tk.

4. SK 9032.1AZBHK - 132SP/4 TF F
Type: Helical Bevel Gears BLOCK
Input Speed: 1465 1/min
Ratio: 23.91
Output Speed: 61 1/min
Service Factor: 1.8
Output torque: 857 Nm
Power: 5,5 kW
Voltage: 400/690 V
Efficiency Class: IE3
Mounting Pos: M1
Output Shaft: Hollow Keyed 50H7 mm
Gearbox Options: Shaft Fixing Kit; Cover Hollow Shaft; Bottom Mount Torque Arm
Motor Cooling: TEBC Totally Enc Blower Cooled 3ph & 1ph 220-575V 50/60Hz
Paint Color: RAL 5010 Blue
Kogus: 2 tk.

Kõik mootorreduktorid on uued ning kasutamata, pakitud originaalpakendites euro alustel.
Reduktorites on olemas vajalik õlikogus tootmiseks määratud asendis (vt. näidispildid).
Toodud 2023 aasta alguses.
Küsimuste korral võib saada detailsemat datasheeti
