Tp-link tl-er5120 gigabit load balance broadband router v4

tp-link tl-er5120 gigabit load balance broadband router v4

SECURITY

Access Control

Source/Destination IP Based Access Control

Filtering

MAC Filtering
URL/Keywords Filtering

ARP Inspection

Sending GARP Packets
ARP Scanning by WAN/LAN
IP-MAC Binding

Attack Defense

TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN

HARDWARE FEATURES

Standards and Protocols

IEEE 802.3, IEEE802.3u, IEEE802.3ab
TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, PPTP, L2TP

Interface

1 Gigabit WAN port
3 Gigabit LAN/WAN ports
1 Gigabit LAN port

Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)

Button

Reset Button

Power Supply

Internal Universal Power Supply
AC100-240V~ 50/60Hz Input

Flash

32MB

DRAM

DDRIII 256MB

LED

PWR, SYS, Link/Act, Speed, WAN

Dimensions ( W x D x H )

17.3 x 8.7 x 1.7 in.(440x220x44 mm)
19-inch Standard Rack-Mount Width, 1U Height

PERFORMANCE

Concurrent Session

150K

NAT Throughput

800Mbps

NAT(iMIX)

703Mbps

NAT(DHCP)

934Mbps

NAT(PPPoE)

868Mbps

BASIC FUNCTIONS

WAN Connection Type

Static/Dynamic IP
PPPoE/Russian PPPoE
PPTP/Russian PPTP
L2TP/Russian L2TP
Bigpond Cable

MAC Clone

Modify WAN MAC Address

DHCP

DHCP Server/Client
DHCP Address Reservation

IPv6

IPv6 Support

VLAN

802.1Q VLAN, Port VLAN

IPTV

Bridge, Custom

TRANSMISSION

Load Balance

Intelligent Load Balance
Link Backup (Timing, Failover)
Online Detection

NAT

One-to-One NAT
Multi-nets NAT
Virtual Server
Port Triggering
FTP/H.323/SIP/IPsec/PPTP ALG
UPnP

Routing

Static Routing
Policy Routing

Session Limit

IP-based Session Limit

Bandwidth Control

IP-based Bandwidth Control

AUTHENTICATION

Web Authentication

Local User Authentication
Radius Sever Authentication
Onekey Online

Management Features

Service

Dynamic DNS (Dyndns, No-IP)

Maintenance

Web Management Interface
Remote Management
Export & Import Configuration
SNMP
Diagnostics(Ping & Traceroute)
NTP Synchronize
Syslog Support

OTHERS

Certification

FCC, RoHS

Package Content

TL-ER5120
Power Cord
Rack-mount Kit
Installation Guide

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
