Roksan Caspian M2 усилитель мощности

Müüa lõppvõimendi Roksan Caspian M2 Power amp

Specifications:
Inputs Input 1 (Balanced): 1x pair XLR sockets
Input 2 (Single ended): 1x pair RCA sockets
Input Impedance 38 kΩ
Input Sensitivity 240mV RMS
Signal Input L+R channels. Balanced and single ended
Signal Output Chain output L+R channels. Balanced and single ended
Outputs Output 1: 1x pair RCA sockets
Output2: 1x pair XLR 3 pin plugs
Output Voltage 700mV
Power Output 1x pair loudspeakers 4mm socket L+R
Output Power 85 Watts, into 8Ω both channels driven
125 Watts, into 4Ω both channels driven
Power Supply 350VA Ultra Low Noise Toroidal Transformer
Current Output 60 Amps Peak to Peak
Damping Factor 160 Amps measured at 8Ω
Frequency response -3dB, <3Hz. > 1000kHz
Gain 31.6dB straight or untrimmed, 0.316 untrimmed to fully trimmed
Harmonic Distortion 0.005% 1kHz, into 8Ω
Signal to Noise Ratio Line 108dBa (ref. 900mV)
Power Source 100V/120V, 50Hz/60Hz, 220V/240V, 50Hz/60Hz
Power Consumption Full power 2 channels 8Ω
< 330 W 4Ω <550W
Dimension 432 x 330 x 70 (WxDxH) mm
432 x 330 x 80 (including feet)
Weight 13 Kg
Made in UK
